Blueprints provide a way to define your Pangolin resources and their configurations in a structured, declarative format. This allows for easier management, version control, and automation of your resource setups.

​
Overview

Pangolin supports two blueprint formats:
  1. YAML Configuration Files: Standalone configuration files
  2. Docker Labels: Configuration embedded in Docker Compose files

​
YAML Configuration Format

​
Proxy Resources

Proxy resources are used to expose HTTP, TCP, or UDP services through Pangolin. Below is an example configuration for proxy resources:
proxy-resources:
  resource-nice-id-uno:
    name: this is a http resource
    protocol: http
    full-domain: uno.example.com
    host-header: example.com
    tls-server-name: example.com
    headers:
      - name: X-Example-Header
        value: example-value
      - name: X-Another-Header
        value: another-value
    rules:
      - action: allow
        match: ip
        value: 1.1.1.1
      - action: deny
        match: cidr
        value: 2.2.2.2/32
      - action: pass
        match: path
        value: /admin
    targets:
    - site: lively-yosemite-toad
      hostname: localhost
      method: http
      port: 8000
    - site: slim-alpine-chipmunk
      hostname: localhost
      path: /admin
      path-match: exact
      method: https
      port: 8001
  resource-nice-id-dos:
    name: this is a raw resource
    protocol: tcp
    proxy-port: 3000
    targets:
    - site: lively-yosemite-toad
      hostname: localhost
      port: 3000

​
Authentication Configuration

Authentication is off by default. You can enable it by adding the relevant fields in the auth section as shown in the example below.
proxy-resources:
  secure-resource:
    name: Secured Resource
    protocol: http
    full-domain: secure.example.com
    auth:
      pincode: 123456
      password: your-secure-password
      sso-enabled: true
      sso-roles:
        - Member
        - Admin
      sso-users:
        - user@example.com
      whitelist-users:
        - admin@example.com

​
Targets-Only Resources

You can define simplified resources that contain only target configurations. This is useful for adding targets to existing resources or for simple configurations:
proxy-resources:
  additional-targets:
    targets:
    - site: another-site
      hostname: backend-server
      method: https
      port: 8443
    - site: another-site
      hostname: backup-server
      method: http
      port: 8080
When using targets-only resources, the name and protocol fields are not required. All other resource-level validations are skipped for these simplified configurations.

​
Client Resources

Client resources are only accessible when connected via an Olm client:
client-resources:
  client-resource-nice-id-uno:
    name: this is my resource
    protocol: tcp
    proxy-port: 3001
    hostname: localhost
    internal-port: 3000
    site: lively-yosemite-toad

​
Docker Labels Format

For containerized applications, you can define blueprints using Docker labels.

​
Enabling Docker Socket Access

To use Docker labels, enable the Docker socket when running Newt:
newt --docker-socket /var/run/docker.sock <other-args>
or using the environment variable:
DOCKER_SOCKET=/var/run/docker.sock

​
Docker Compose Example

services:
  newt:
    image: fosrl/newt
    container_name: newt
    restart: unless-stopped
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
    environment:
      - PANGOLIN_ENDPOINT=https://p.fosrl.io
      - NEWT_ID=h1rbsgku89wf9z3
      - NEWT_SECRET=z7g54mbcwkglpx1aau9gb8mzcccoof2fdbs97keoakg2pp5z
      - DOCKER_SOCKET=/var/run/docker.sock

  nginx1:
    image: nginxdemos/hello
    container_name: nginx1
    labels:
      # Proxy Resource Configuration
      - pangolin.proxy-resources.nginx.name=nginx
      - pangolin.proxy-resources.nginx.full-domain=nginx.fosrl.io
      - pangolin.proxy-resources.nginx.protocol=http
      - pangolin.proxy-resources.nginx.headers[0].name=X-Example-Header
      - pangolin.proxy-resources.nginx.headers[0].value=example-value
      # Target Configuration - the port and hostname will be auto-detected
      - pangolin.proxy-resources.nginx.targets[0].method=http
      - pangolin.proxy-resources.nginx.targets[0].path=/path
      - pangolin.proxy-resources.nginx.targets[0].path-match=prefix

  nginx2:
    image: nginxdemos/hello
    container_name: nginx2
    labels:
        # Additional target for the same resource where the port and hostname are explicit
      - pangolin.proxy-resources.nginx.targets[1].method=http
      - pangolin.proxy-resources.nginx.targets[1].hostname=nginx2
      - pangolin.proxy-resources.nginx.targets[1].port=80

networks:
  default:
    name: pangolin_default
This will create a resource that looks like the following:
Example resource

Pangolin UI showing Docker Compose blueprint example

​
Docker Labels Considerations

Automatic Discovery

When hostname and internal port are not explicitly defined in labels, Pangolin will automatically detect them from the container configuration.

Site Assignment

If no site is specified in the labels, the resource will be assigned to the Newt site that discovered the container.

Configuration Merging

Configuration across different containers is automatically merged to form complete resource definitions. This allows you to distribute targets across multiple containers while maintaining a single logical resource.

​
Configuration Properties

​
Proxy Resources

PropertyTypeRequiredDescriptionConstraints
namestringConditionalHuman-readable name for the resourceRequired unless targets-only resource
protocolstringConditionalProtocol type (http, tcp, or udp)Required unless targets-only resource
full-domainstringHTTP onlyFull domain name for HTTP resourcesRequired for HTTP protocol, must be unique
proxy-portnumberTCP/UDP onlyPort for raw TCP/UDP resourcesRequired for TCP/UDP, 1-65535, must be unique within proxy-resources
sslbooleanNoEnable SSL/TLS for the resource-
enabledbooleanNoWhether the resource is enabledDefaults to true
host-headerstringNoCustom Host header for requests-
tls-server-namestringNoSNI name for TLS connections-
headersarrayNoCustom headers to add to requestsEach header requires name and value (min 1 char each)
rulesarrayNoAccess control rulesSee Rules section below
authobjectHTTP onlyAuthentication configurationSee Authentication section below
targetsarrayYesTarget endpoints for the resourceSee Targets section below

​
Target Configuration

PropertyTypeRequiredDescriptionConstraints
sitestringNoSite identifier where the target is located-
hostnamestringYesTarget hostname or IP address-
portnumberYesPort on the target system1-65535
methodstringHTTP onlyProtocol method (http, https, or h2c)Required for HTTP protocol targets
enabledbooleanNoWhether the target is enabledDefaults to true
internal-portnumberNoInternal port mapping1-65535
pathstringHTTP onlyPath prefix, exact path, or regex pattern-
path-matchstringHTTP onlyPath matching type (prefix, exact, or regex)-

​
Authentication Configuration

Not allowed on TCP/UDP resources.
PropertyTypeRequiredDescriptionConstraints
pincodenumberNo6-digit PIN for accessMust be exactly 6 digits
passwordstringNoPassword for access-
sso-enabledbooleanNoEnable SSO authenticationDefaults to false
sso-rolesarrayNoAllowed SSO rolesCannot include “Admin” role
sso-usersarrayNoAllowed SSO user emailsMust be valid email addresses
whitelist-usersarrayNoWhitelisted user emailsMust be valid email addresses

​
Rules Configuration

PropertyTypeRequiredDescriptionConstraints
actionstringYesRule action (allow, deny, or pass)-
matchstringYesMatch type (cidr, path, ip, or country)-
valuestringYesValue to match againstFormat depends on match type

​
Client Resources

These are resources used with Pangolin Olm clients (e.g., SSH, RDP).
PropertyTypeRequiredDescriptionConstraints
namestringYesHuman-readable name for the resource2-100 characters
protocolstringYesProtocol type (tcp or udp)-
proxy-portnumberYesPort accessible to clients1-65535, must be unique within client-resources
hostnamestringYesTarget hostname or IP address1-255 characters
internal-portnumberYesPort on the target system1-65535
sitestringNoSite identifier where the resource is located2-100 characters
enabledbooleanNoWhether the resource is enabledDefaults to true

​
Validation Rules and Constraints

​
Resource-Level Validations

  1. Targets-Only Resources: A resource can contain only the targets field, in which case name and protocol are not required.
  2. Protocol-Specific Requirements:
    • HTTP Protocol: Must have full-domain and all targets must have method field
    • TCP/UDP Protocol: Must have proxy-port and targets must NOT have method field
    • TCP/UDP Protocol: Cannot have auth configuration
  3. Port Uniqueness:
    • proxy-port values must be unique within proxy-resources
    • proxy-port values must be unique within client-resources
    • Cross-validation between proxy and client resources is not enforced
  4. Domain Uniqueness: full-domain values must be unique across all proxy resources
  5. Target Method Requirements: When protocol is http, all non-null targets must specify a method

​
Common Validation Errors

When working with blueprints, you may encounter these validation errors:

​
“Admin role cannot be included in sso-roles”

The Admin role is reserved and cannot be included in the sso-roles array for authentication configuration.

​
”Duplicate ‘full-domain’ values found”

Each full-domain must be unique across all proxy resources. If you need multiple resources for the same domain, use different subdomains or paths.

​
”Duplicate ‘proxy-port’ values found”

Port numbers in proxy-port must be unique within their resource type (proxy-resources or client-resources separately).

​
”When protocol is ‘http’, all targets must have a ‘method’ field”

All targets in HTTP proxy resources must specify whether they use http, https, or h2c.

​
”When protocol is ‘tcp’ or ‘udp’, targets must not have a ‘method’ field”

TCP and UDP targets should not include the method field as it’s only applicable to HTTP resources.

​
”When protocol is ‘tcp’ or ‘udp’, ‘auth’ must not be provided”

Authentication is only supported for HTTP resources, not TCP or UDP.

​
”Resource must either be targets-only or have both ‘name’ and ‘protocol’ fields”

Resources must either contain only the targets field (targets-only) or include both name and protocol for complete resource definitions.
